Product Description

Water Pump 15HP 480V 60Hz 5 Inch of 304/316 Stainless Steel Tsm-15125

- Name of pump:Water Pump 15HP 480V 60HZ 5 Inch of 304/316 Stainless Steel

- Pump Type: Centrifugal Pump

- Pump model:TSM-15125

- Pump brand: ATACH

-Installation Type: Horizontal Close-Coupled

- Impeller Quantity: 1 pcs

- Rated pump capacity: 120 m3/h

- Rated pump head: 28 m

- Power/speed: 15 HP /2900 r.p.m

- Power supply: 3 phase/380V/50HZ
(also supply special voltage,special frequency, explosion-proof motor, High efficiency and energy saving motor )

- Material Supply: SUS304,SUS316,SUS316L

- Shaft Seal: Mechanical seal

- Inlet / outlet : 125mm*125mm

- NPSH: /

- Main usage:

1. Cold and hot water cycle	8.Cooling tower water cycle
2. Industrial water supply	9.Painting equipment water cycle
3.High-rise building pressurized water supply	10.Electroplating and electrophoresis equipment water use
4. Fire water supply
5.Civil construction water
6. Boiler water supply
7. Sewage treatment equipment
