Vertical Single Stage Pump (ISG)

Technical Parameter(50Hz):

Capacity: 6.3-1600 m3/h
Lift Head: 5-150 m
Rotary Speed: 980, 1480, 2950 r/min
Calibre: Φ 15 to Φ 500
Temperature: 0 to +120degrees
Working Pressure: ≤ 1.6 Mpa

Application:

1. Send the fresh water
2. Suitable for industry and city's giving and draining off water

3. It is convenient to form a complete set with other apparatus
4. High efficiency, low noise

5. There are cold water types, hot water type, high temperature type, chemical industry type, oil type
6. Performance is reliable
7. International standard

Performance and Advantages:

Highly efficiency, Energy saving, With tube-type structure, easy for installation, Electro-mechanically integrated design, Space efficient, Easy for service just by disassembling the nut of the pump bonnet and taking out the motor and the actuator unit. Wide application scope
