Cheap Mission Replacement Oil Field Mud Sand Pump
Cheap Mission Replacement Oil field Mud Sand PumpCharacteristics TypeSpeedCapacityHeadEfficiencyMotor PowerWeight(r/min)(m³/h)(m)(%)(kw)(kg)MSB10x8x141450/1750260-300336575/901150/1300MSB8x6x141450/1750240-260336555/75830/1100MSB8x6x111450/1750240266537/45700/750MSB6x5x141450/1750220286537/......
Send Inquiry
Product Description
Cheap Mission Replacement Oil field Mud Sand Pump
Characteristics
Description
The SB sand pumps is designed for pumping drilling fluid or industrial suspension (slurry), the use of advanced design theory can be pumping abrasive, liquid viscosity (resistance) and corrosion. Compared with an ordinary pump, excellent flow, high temperature, long life, easy maintenance, high reliability, significant energy saving effect and so on, now widely used around the world on land and offshore drilling. We will provide users with the best products to meet the needs of the different working conditions.
Features
Pump housings are heavier and stronger to outlast conventional pumps
The impeller is designed to reduce turbulence, lower radial and thrust loads, and provides a smooth flow of fluid through the pump
The MSB series shaft has a greater diameter to provide heavy-duty performance with minimal shaft deflection.
Bearings are designed for easy maintenance.
Stuffing box cover combines the functions of wear plate and stuffing box into a one-piece replacement unit.
Application
Drilling applications
Details
FAQ
A: What kind of company you are?
Q: We are centrifugal pump manufacture located in Boy Town, Baoding, China, with more than 20years experiences. We were gaining good reputation among our customers for our professional, warm and thoughtful service. Because we know that a long terms business based on the quality control, price, packing, delivery time etc.
A: What's the quality assurance you provided and how do you control quality?
Q: Established a procedure to check products at all stages of the manufacturing process: Casting, Heat treatment, Machining, Assembly, and Testing.
Q: Can you install the motor or diesel engine with the pump for us?
A: yes, we can, it's no problem, and we are experienced in this.
Q: What's your MOQ?
A: Trial sample order is OK.
Q: What are your payment terms?
A: T/T, L/C, D/P, D/A......
Q: What certificates do you have?
A: CE, ISO 2008, UL.....
Q: How about the warranty?
A: One year warranty for pumps, it depends on other pump working condition details.
Q: What is the delivery time?
A: 15-30 days according to customer quantities.
Q: Can you do OEM brand?
A: Yes, Welcome.
Q: What information should I offer to get pump solution?
1, Material:
2, Head: m
3, Flow: m3/h
4, Medium size: mm
5, Particle shape (smooth or sharp):
6, Medium pH level:
7, Temperature:
8, Drive type:
9. Power supply:
Contact me for detail offer with curve and drawing!
Helen Gao
Mob: +86 158 3083 2118
Tel: +86 312 6791280
Fax: +86 312 3085383
Characteristics
| Type | Speed | Capacity | Head | Efficiency | Motor Power | Weight |
| (r/min) | (m³/h) | (m) | (%) | (kw) | (kg) | |
| MSB10x8x14 | 1450/1750 | 260-300 | 33 | 65 | 75/90 | 1150/1300 |
| MSB8x6x14 | 1450/1750 | 240-260 | 33 | 65 | 55/75 | 830/1100 |
| MSB8x6x11 | 1450/1750 | 240 | 26 | 65 | 37/45 | 700/750 |
| MSB6x5x14 | 1450/1750 | 220 | 28 | 65 | 37/45 | 700/750 |
| MSB6x5x11 | 1450/1750 | 200 | 26 | 65 | 30/37 | 655/687 |
| MSB5x4x14 | 1450/1750 | 120 | 26 | 65 | 22 | 510 |
| MSB4x3x13 | 1450/1750 | 60-80 | 26-30 | 65 | 11/15 | 395/405 |
| MSB3x2x13 | 1450/1750 | 40-60 | 25-28 | 65 | 7.5/11 | 335/385 |
Description
The SB sand pumps is designed for pumping drilling fluid or industrial suspension (slurry), the use of advanced design theory can be pumping abrasive, liquid viscosity (resistance) and corrosion. Compared with an ordinary pump, excellent flow, high temperature, long life, easy maintenance, high reliability, significant energy saving effect and so on, now widely used around the world on land and offshore drilling. We will provide users with the best products to meet the needs of the different working conditions.
Features
Pump housings are heavier and stronger to outlast conventional pumps
The impeller is designed to reduce turbulence, lower radial and thrust loads, and provides a smooth flow of fluid through the pump
The MSB series shaft has a greater diameter to provide heavy-duty performance with minimal shaft deflection.
Bearings are designed for easy maintenance.
Stuffing box cover combines the functions of wear plate and stuffing box into a one-piece replacement unit.
Application
Drilling applications
Details
FAQ
A: What kind of company you are?
Q: We are centrifugal pump manufacture located in Boy Town, Baoding, China, with more than 20years experiences. We were gaining good reputation among our customers for our professional, warm and thoughtful service. Because we know that a long terms business based on the quality control, price, packing, delivery time etc.
A: What's the quality assurance you provided and how do you control quality?
Q: Established a procedure to check products at all stages of the manufacturing process: Casting, Heat treatment, Machining, Assembly, and Testing.
Q: Can you install the motor or diesel engine with the pump for us?
A: yes, we can, it's no problem, and we are experienced in this.
Q: What's your MOQ?
A: Trial sample order is OK.
Q: What are your payment terms?
A: T/T, L/C, D/P, D/A......
Q: What certificates do you have?
A: CE, ISO 2008, UL.....
Q: How about the warranty?
A: One year warranty for pumps, it depends on other pump working condition details.
Q: What is the delivery time?
A: 15-30 days according to customer quantities.
Q: Can you do OEM brand?
A: Yes, Welcome.
Q: What information should I offer to get pump solution?
1, Material:
2, Head: m
3, Flow: m3/h
4, Medium size: mm
5, Particle shape (smooth or sharp):
6, Medium pH level:
7, Temperature:
8, Drive type:
9. Power supply:
Contact me for detail offer with curve and drawing!
Helen Gao
Mob: +86 158 3083 2118
Tel: +86 312 6791280
Fax: +86 312 3085383
