1500m3/H Centrifugal Submersible Pump for Sea Dredging
1500m3/h Centrifugal Submersible Pump for Sea DredgingCharacteristics ·Type:·Media:·Application:centrifugalslurrytransporting·Other characteristics:·Flow rate:·HeadSingle-stageMin.:0m3/hMin.: 0m Max.: 2412m3/hMax.: 64m·Prim......
Send Inquiry
Product Description
1500m3/h Centrifugal Submersible Pump for Sea Dredging
Characteristics
Description
The Modo SS Series Submersible Slurry Pumps are electro submersible centrifugal pumps designed for pumping abrasive and high density slurries in mining, heavy industry, civil construction and municipal applications.
Features
Submersible work without influence of suction head;
No assistant vacuum pump, save invest;
No noise, keep the silence of work station;
With agitator, no need extra stirring devices, more convenience for operating;
It need not build pump house.
Directly work on the surface of slurry, with higher efficiency to deliver slurry.
Application
Transfer of waste water, effluent and solids laden water for
Water Treatment
Building Services
Sumps and Basements
Mining
Civil Construction
Industry
Municipal
Processing
Details
FAQ
A: What kind of company you are?
Q: We are centrifugal pump manufacture located in Boy Town, Baoding, China, with more than 20years experiences. We were gaining good reputation among our customers for our professional, warm and thoughtful service. Because we know that a long terms business based on the quality control, price, packing, delivery time etc.
A: What's the quality assurance you provided and how do you control quality?
Q: Established a procedure to check products at all stages of the manufacturing process: Casting, Heat treatment, Machining, Assembly, and Testing.
Q: Can you install the motor or diesel engine with the pump for us?
A: yes, we can, it's no problem, and we are experienced in this.
Q: What's your MOQ?
A: Trial sample order is OK.
Q: What are your payment terms?
A: T/T, L/C, D/P, D/A......
Q: What certificates do you have?
A: CE, ISO 2008, UL.....
Q: How about the warranty?
A: One year warranty for pumps, it depends on other pump working condition details.
Q: What is the delivery time?
A: 15-30 days according to customer quantities.
Q: Can you do OEM brand?
A: Yes, Welcome.
Q: What information should I offer to get pump solution?
1, Material:
2, Head: m
3, Flow: m3/h
4, Medium size: mm
5, Particle shape (smooth or sharp):
6, Medium pH level:
7, Temperature:
8, Drive type:
9. Power supply:
Contact me for detail offer with curve and drawing!
Helen Gao
Mob: +86 158 3083 2118
Tel: +86 312 6791280
Fax: +86 312 3085383
Characteristics
| ·Type: | ·Media: | ·Application: |
| centrifugal | slurry | transporting |
| ·Other characteristics: | ·Flow rate: | ·Head |
| Single-stage | Min.:0m3/h | Min.: 0m |
| Max.: 2412m3/h | Max.: 64m | |
| ·Priming | ||
| submersible |
Description
The Modo SS Series Submersible Slurry Pumps are electro submersible centrifugal pumps designed for pumping abrasive and high density slurries in mining, heavy industry, civil construction and municipal applications.
| Item | Submersible slurry pump |
| Model | SS |
| Material | 27% Chrome White Iron, SS 304,SS 316, or customized |
| Color | Decided by user |
| Mode | Submersible |
| Impeller | single impeller |
| Drive | Direct coupling |
| Seal | Packing seal or mechanical seal |
| Speed | 1460r/min,980r/min |
| Theory | Centrifugal pump |
| Structure | Single stage pump |
| Usage | High density slurries with solids etc. |
| Power | Electric motor |
| Standard | ISO |
| Application | Mining. civil construction, industry, dredging |
| Outlet diameter | 3.15-16inches |
| Capacity | 22-2400 m3/h |
| Head | 8.6-70m |
| Power | 7.5-315kw |
| Warranty | 1year |
| Certificate | ISO9001 |
| OEM | Acceptable |
| Max Solids Dia | 2.4 inches |
Features
Submersible work without influence of suction head;
No assistant vacuum pump, save invest;
No noise, keep the silence of work station;
With agitator, no need extra stirring devices, more convenience for operating;
It need not build pump house.
Directly work on the surface of slurry, with higher efficiency to deliver slurry.
Application
Transfer of waste water, effluent and solids laden water for
Water Treatment
Building Services
Sumps and Basements
Mining
Civil Construction
Industry
Municipal
Processing
Details
FAQ
A: What kind of company you are?
Q: We are centrifugal pump manufacture located in Boy Town, Baoding, China, with more than 20years experiences. We were gaining good reputation among our customers for our professional, warm and thoughtful service. Because we know that a long terms business based on the quality control, price, packing, delivery time etc.
A: What's the quality assurance you provided and how do you control quality?
Q: Established a procedure to check products at all stages of the manufacturing process: Casting, Heat treatment, Machining, Assembly, and Testing.
Q: Can you install the motor or diesel engine with the pump for us?
A: yes, we can, it's no problem, and we are experienced in this.
Q: What's your MOQ?
A: Trial sample order is OK.
Q: What are your payment terms?
A: T/T, L/C, D/P, D/A......
Q: What certificates do you have?
A: CE, ISO 2008, UL.....
Q: How about the warranty?
A: One year warranty for pumps, it depends on other pump working condition details.
Q: What is the delivery time?
A: 15-30 days according to customer quantities.
Q: Can you do OEM brand?
A: Yes, Welcome.
Q: What information should I offer to get pump solution?
1, Material:
2, Head: m
3, Flow: m3/h
4, Medium size: mm
5, Particle shape (smooth or sharp):
6, Medium pH level:
7, Temperature:
8, Drive type:
9. Power supply:
Contact me for detail offer with curve and drawing!
Helen Gao
Mob: +86 158 3083 2118
Tel: +86 312 6791280
Fax: +86 312 3085383
